Description
Slim and elegant design
Vandal resistant metal housing, IP65
Card read range: 0.78 to 1.96 in. (10 to 50 mm)
BioNANO algorithm ensures fast verification under 0.5s
LED indicators and buzzer for visual and audio feedback
Multiple verification modes guarantee flexibility and safety
Multiple communication modes such as TCP/IP, Wiegand 26/34, easy for installation and integration
Tamper alarm output
| Capacity | ||
|---|---|---|
| Fingerprint Capacity | 3,000 | |
| Card Capacity | 3,000 | |
| Log Capacity | 50,000 | |
| Inferface | ||
| Relay | Relay Output | |
| Feature | ||
| Identification Mode | Fingerprint/Card | |
| Network Port | TCP/IP, Optional Bluetooth | |
| Wiegand Protocol | Support Wiegand 26 | |
| Log Capacity | 50,000 | |
| Verification Speed | < 0.5s(1:N) | |
| Card Read Range | 0.78 to 1.96 in. (10 to 50 mm) | |
| Hardware | ||
| Operating Voltage | DC 12V | |
| Work Current | 150mA | |
| Operating Temperature | -30°C to 60°C | |
| Humidity | 20% to 90% Non-Condensing | |
| Size(WxHxD) | 19.7 x 48.8 x 13.6 in. (50 x 124 x 34.5 mm) | |
| Accessory | SC011(Controller) | |
| Certificate | FCC, CE, RoHS | |
M5 Pro
| Title | Description | Version | Size | Hits | Date added | Date modified | Download |
|---|---|---|---|---|---|---|---|
| Anviz_M5Pro_QuickGuide_EN_09.05.2018 | 2.18 MB | 211 | 19-12-2021 | 19-12-2021 | DownloadPreview | ||
| Anviz_M5Pro_Catalogue_EN_07.16.2018 | 339.64 KB | 193 | 19-12-2021 | 19-12-2021 | DownloadPreview |
